Кабел USB2.0 to RS232 1.2m VCOM
Технически спецификации
Конектор 1: USB 2.0 male (type A)
Конектор 2: D-SUB/RS-232 male (9-pin)
Дължина на кабела: 1,20 m
Тип кабел: Кръгъл кабел
Материал на вътрешния проводник: CU (мед)
Брой екранировки: 2x
Макс. скорост на предаване: 0.48 Gbit / s
Съвместимост: USB 1.1 and USB 2.0
Съвместим с: Windows 2000, XP, VISTA, 7, 8 and 10
Опаковка: 1 бр. в полиетиленов пакет
Маркировки CE, WEEE
EAN: 4895182214439
Specifications:
Chipset: CH340
Full-speed USB device interface, USB 2.0 compatible.
Emulate standard UART interface, used to upgrade the original serial peripheral or expand additional UART via USB.
Original UART applications are totally compatible without any modification in Windows operating systems.
Hardware full duplex UART interface, integrated transmit-receive buffer, supports communication baud rate varies from 50bps to 2Mbps.
Supports common MODEM interface signals RTS, DTR, DCD, RI, DSR and CTS.
Provides further RS232, RS485, RS422 interface, etc. through external voltage conversion chip.
CH340R supports IrDA criterion SIR infrared communication, supports baud rate varies from 2400bps to 115200bps.
Built-in firmware, software compatible with CH341, use VCP driver of CH341 directly.
Supports 5V and 3.3V power supply voltages.
CH340C/N/K/E/X/B have integrated clock, no external crystal required, CH340B also integrates EEPROM used to configure the serial number, etc.
RoHS compliant SOP-16, SOP-8, SSOP-20 and ESSOP-10, MSOP-10 lead-free package.
