Avery AP 5.4 300 DPI RED COVER Thermal Label Printer
(Принтра разботи но главата печати до половината)
AVERY DENNISON BARCODE PRINTER AP 5.4
Avery Dennison ® AP 5.4 Tabletop Bar Code Printer
Dimensions:
Height: 272 mm (10.70”)
Width: 260 mm (10.23”)
Depth: 462 mm (18.18”)
Weight:
14kg (30.86 lbs)
Printing Method:
Thermal direct/transfer
Printhead:
203 or 300 dpi
Memory:
ROM: 4 MB Flash
RAM: 64 MB SDRAM
Bar Codes:
EAN 8, EAN 13 with add-on 2 and 5;
UPC-A, UPC-E; Code 39; Code 39
extended; Code 39 Ratio 3:1; Code
39 Ratio 2,5:1; ITF, Codabar; Code
128 A, B, C; Code 128 UPS; Code
128 Pharmacy; Code 2/5 Matrix; Code
2/5 Interleaved; Code 2/5 5; Code 2/5
Interleaved Ratio 1:3; Code 2/5 Matrix
Ratio 1:2,5; Code 2/5 Matrix Ratio 1:3;
MSI; EAN 128; Postcode (Guide and
Identity Code); All bar codes scalable
in 16 widths and height; 2-dimensional
Data Matrix Code; Maxi Code; PDF 417;
Codablock F; Code 49; QR Matrix Code;
GS1 Databar; EAN/UCC composite
symbology
Standard Fonts:
17 fonts including OCR-A and OCR-B;
three scalable fonts, TrueType® fonts
(also unicoded) supported. All font types
can be stored on an SD card
Font Magnification:
Rotation by 0°, 90°, 180° and 270°. Up
to factor 8 scaling in X/Y direction.
Keypad/Display:
Illuminated LCD graphics display with
two lines of 16 characters.
Printer Warranty:
One (1) year parts and labour. Full written
warranty statement available on request.
Printhead Warranty:
One (1) million inches or six (6) months,
whichever occurs first.
Supplies
Only Avery Dennison supplies are
recommended.
Supply Sizes:
Width:15mm to 120mm (0.59” to 4.72”)
Supply Roll Size:
OD: up to 210mm (up to 8.26”)
Core Diameter: 38mm, 76mm, 102mm
(1.50”, 3” 4”)
Min/Max Material Thickness:
Self-adhesive labels: 60-160 gsm
(0.13lbs - 0.35lbs)
Cardboard labels: max 240 gsm
(0.53 lbs)
Ribbon/Foil Length:
Up to 500m (1640.19’)
Ribbon/Foil Width:
25mm to 110mm (0.98” to 4.33)
Performance
Power Source:
100 - 240 V (AC); Mains frequency
60/50 Hz
Processor:
32 Bit RMI CPU
Print Speed:
50-200 mm/s; 50-150 mm/s
Communications
Standard Communication Ports:
10/100 Base-T Ethernet
2 x USB
RS232 Serial
Options
• Cutter
• Internal rewinder
• External rewinder
• Dispenser light barrier
• Keyboard
• SD card
