XVR5116HS-I2
16 Channel Penta-brid 5M-N/1080P Compact 1U 1HDD WizSense Digital Video Recorder
> H.265+/H.265 dual-stream video compression
> Supports HDCVI/AHD/TVI/CVBS/IP video inputs
> Max 24 channels IP camera inputs, each channel up to 6MP; Max 128 Mbps incoming bandwidth
> Up to 2 channels video stream ( analog channel ) Perimeter Protection
> Up to 16 channels video stream ( analog channel ) SMD Plus
> Up to 2 channels video stream (analog channel ) human face recognition
> IoT & POS functionaliti
------------------------------------------------------------------------------------------------------
System
Main Processor
Embedded Processor
Operating System
Embedded LINUX
Perimeter Protection
Performance
2 channels, 10 IVS for each channel
Object classification
Human/Vehicle secondary recognition for tripwire and intrusion
AI Search
Search by target classification (Human, Vehicle)
Face Recognition
Performance
Max 12 face pictures/sec processing
2 channels video stream face recognition, only support analog camera
Stranger Mode
Detect strangers` faces (not in device`s face database). Similarity threshold can be set manually.
AI Search
Up to 8 target face images search at same time, similarity threshold can be set for each target face image.
Database Management
Up to 10 face databases with 10,000 face images in total. Name, gender, birthday, address, certificate type, cerificate No., countries®ions and state can be added to each face picture.
Database Application
Each database can be applied to video channels independently .
Trigger Events
Buzzer, Voice Prompts, Email, Snapshot, Recording, Alarm Out, PTZ Activation, etc.
SMD Plus
Performance
16 channels
AI Search
Search by target classification (Human, Vehicle)
Video and Audio
Analog Camera Input
16 channels, BNC
HDCVI Camera Input
5MP, 4MP, 1080P@25/30fps, 720P@50/60fps, 720P@25/30fps
AHD Camera Input
5MP, 4MP, 1080P@25/30, 720P@25/30fps
TVI Camera Input
5MP, 4MP, 1080P@25/30, 720P@25/30fps
CVBS Camera Input
PAL/NTSC
IP Camera Input
16+8 channels, each channel up to 6MP
Audio In/Out
1/1, RCA
Two-way Talk
Reuse audio in/out, RCA
Recording
Compression
AI Coding/H.265+/H.265/H.264+/H.264
Resolution
5M-N, 4M-N, 1080P, 1080N, 720P, 960H, D1, CIF
Record Rate
Main stream: All channel 5M-N (1fps–10fps); 4M-N/1080P (1fps–15fps); 1080N/720P/960H/
D1/CIF (1fps–25/30fps)
Sub stream: D1/CIF (1fps–15fps)
Bit Rate
32 Kbps–6144 Kbps Per Channel
Record Mode
Manual, Schedule (General, Continuous), MD (Video detection: Motion Detection, Video Loss, Tampering), Alarm, Stop
Record Interval
1 – 60 min (default: 60 min), Pre-record: 1 s–30 s, Post-record: 10 s–300 s
Audio Compression
G.711A, G.711U, PCM
Audio Sample Rate
8 KHz, 16 bit Per Channel
Audio Bit Rate
64 Kbps Per Channel
Display
Interface
1 HDMI ,1 VGA
Resolution
VGA: 1920 ? 1080, 1280 ? 1024, 1280 ? 720
HDMI: 3840 ? 2160, 1920 ? 1080, 1280 ? 1024, 1280 ? 720
It changes to 1920 ? 1080, 1280 ? 1024, 1280 ? 720 when Face or IVS&SMD is selected in AI Mode.
Multi-screen Display
When IP extension mode not enabled: 1/4/8/9/16
When IP extension mode enabled: 1/4/8/9/16/25
OSD
Camera title, Time, Video loss, Camera lock, Motion detection, Recording
Network
Interface
1 RJ-45 Port (1000 MB)
Network Function
HTTP, HTTPS, TCP/IP, IPv4/IPv6, Wi-Fi, 3G/4G, SNMP, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, FTP, Alarm Server, P2P,IP Search (Supports Dahua IP camera, DVR, NVS, etc.)
Max. User Access
128 users
Smart Phone
iPhone, iPad, Android
Interoperability
ONVIF 16.12, CGI Conformant
Video Detection and Alarm
Trigger Events
Recording, PTZ, Tour, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips
Video Detection
Motion Detection, MD Zones: 396 (22 ? 18), Video Loss, Tampering and Diagnosis
Alarm input
N/A
Relay Output
N/A
Playback and Backup
Playback
1/4/9/16
It changes to 1/4/9 split when Face or IVS&SMD is selected in AI Mode.
Search Mode
Time /Date, Alarm, MD and Exact Search (accurate to second)
Playback Function
Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Repeat, Shuffle, Backup Selection, Digital Zoom
Backup Mode
USB Device/Network
Storage
Internal HDD
1 SATA Port, up to 10TB capacity
eSATA
N/A
Auxiliary Interface
USB
2 USB Ports (1 USB 2.0 , 1 USB 3.0)
RS485
1 Port, for PTZ Control
RS232
N/A
Electrical
Power Supply
DC 12V/2A
Power Consumption
(Without HDD)
<12W
Construction
Dimensions
Compact 1U, 260 mm ? 238 mm ? 48 mm
(10.24`` ? 9.34`` ? 1.87``)
Net Weight
(without HDD)
1.0 kg (2.2 lb)
Gross Weight
1.4 kg (3.1 lb)
Installation
Desktop installation
Environmental
Operating Conditions
-10°C to +55°C (+14°F to +131°F), 0–90% RH
Storage Conditions
-20°C to +70°C (-4°F to +158°F) , 0–90% RH
Third-party Support
Third-party Support
Dahua, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek, and more
Certifications
Certifications
FCC: Part 15 Subpart B
CE: CE-LVD: EN 60950-1/IEC 60950-1
CE-EMC: EN 61000-3-2, EN 61000-3-3, EN 55032, EN 50130, EN 55024
