LSI LS2-FAE10 (Dell 0H924H) – 2-Port IEEE-1394a FireWire PCI Adapter Card
OVERVIEW
The LSI LS2-FAE10 is a standard 32-bit PCI expansion card that adds high-speed IEEE 1394a (FireWire 400) connectivity to desktop computers. Designed with a reliable LSI Logic chipset, it allows seamless connection of digital video cameras (DV/MiniDV), external hard drives, audio interfaces, and other legacy FireWire peripherals.
KEY FEATURES
- Dual External Ports: Features two 6-pin IEEE 1394a FireWire 400 ports on the rear bracket.
- Internal Expansion: Includes an internal 9-pin/10-pin motherboard-style header for connecting a front-panel FireWire port.
- High-Speed Transfer: Supports data transfer rates of 100 Mbps, 200 Mbps, and up to 400 Mbps.
- Plug & Play / Hot-Swappable: Supports hot-plugging and real-time device connection without rebooting.
TECHNICAL SPECIFICATIONS
Model / Part Numbers: LSI LS2-FAE10 / Dell H924H / CN-0H924H
Host Bus Interface: 32-bit PCI (PCI 2.2 compliant)
Chipset: LSI Logic L-FW323-07 (1394a Link/PHY)
External Ports: 2x IEEE 1394a (6-pin Female)
Internal Connectors: 1x 9-pin (2x5) IEEE 1394a Front-Panel Header
Data Transfer Rate: 100 / 200 / 400 Mbps
Standards Compliance: IEEE 1394-1995, IEEE 1394a-2000, OHCI v1.0 & v1.1
Bracket Size: Full-Height (Standard ATX)
OS Compatibility: Windows 98SE / ME / 2000 / XP / Vista / 7 / 8 / 10 (via Legacy Driver), macOS, Linux
